MHB05 410W 480V
Roll over image to zoom in
Click to open expanded view

MHB05 410W 480V

    HEAVY DUTY SERIES V2 - LED 4-WATT UFO High Bay, 410W Max, 189 lm/W, IP65 Wet Location, Select 4X-Wattages, 0-10V Dimmable, Premium Indoor Luminaire, Smart Sensor Ready. (347-480V)

    In stock

    • The MHB05 410W 480V is an industry-leading heavy duty 410W Max LED 4-WATT UFO High Bay luminaire producing 190 lumens per watt.
    • Includes 4X-Wattage (164W, 246W, 328W, 410W) Tuning Switches.
    • Includes a Hook Mount for hanging in high indoor ceiling spaces at or above 25 feet.
    • Optional Pendant Mount available for conduit mounting in dark bronze.
    • Rated IP65 Wet Location and designed for shock resistance with multiple heat-sinks for maximum heat dissipation.
    • Anti-UV Clear Polycarbonate Lens for 100% light transmission and to prevent discoloration.
    • Available with Occupancy, Bi-Level Dimming, Daylight and Sensor Program Remote options.
    • 5 year /50000 hour warranty, and listed with all applicable bodies for safety and performance to qualify for energy-efficient LED lighting rebates.

    SPEC SHEET | MORE FILES

    Model: MHB05 410W 480V Categories: , , Tag:

    Applications

    Premium indoor luminaire for hanging or pendant mounting in high ceiling spaces above 25 feet. Suitable for gymnasiums, warehouses, manufacturing, packaging, storage, aisles, and covered decks.

    Construction

    Manufactured for durability using solid heavy duty die cast aluminum housing with anti-UV polyester coating to resist water, salt, corrosion, discoloration, and scratching. Resistant to shock and vibration. IP65 Wet Location rated for dust tight, water jets: IEC 60529.

    Electrical

    Input voltage 120-277V or 347-480V models with 0-10V Continuous Dimming. Includes 4X-Wattage Tuning Switches. Operating temperatures -40°F to 131°F (-40°C to 55°C).

    Mounting

    Includes a Hook Mount standard. Optional Pendant Mount feature for conduit mounting.

    Optics

    Anti-UV Clear Polycarbonate Lens.

    Controls

    Fixture Mounted PIR Photocell, Bi-Level Dimming, and Motion Detection sensor with Remote Control.

    Listings

    UL certified to meet US and Canadian standards. FCC and RoHS compliant. Listed to qualify for energy-efficient LED lighting rebates.

    Warranty

    5 yr /50K hrs.

    Available Color Temperature

    5000K

    5000K

    Specifications

    Additional information

    Energy DataInput Voltage: 347-480V
    Input Frequency: 50/60 Hz
    Wattage: 4-Wattage Select, 164W, 246W, 328W, 410W
    Power Factor: >0.9
    THD: ≤15%
    Operating Temperature: -40°F to 131°F (-40°C to 55°C)
    Lighting DataLumens: 31000, 45500, 59000, 72000
    Efficacy: 189 lm/W
    CCT: 5000K
    Dimmable: 0-10V
    CRI: Ra≥70
    L70: 50000 hrs
    Physical DataColor: Dark Bronze
    Lens Type: Polycarbonate
    Diffuser: Clear
    Rating: IP65 Wet Location
    Warranty: 5yr/50K
