ETH-UFO-100W-G2

LED UFO High Bay, 100W, IP65 Wet Location, Black, NSF Rated Lens, 0-10V Dimmable (120-277V)

In stock

  • The ETH-UFO-100W-G2 is an industry-leading NSF Lens Rated 100W LED UFO High Bay luminaire producing 152 lumens per watt.
  • Includes a Hook Mount, or Ring Mount for hanging in high indoor ceiling spaces at or above 25 feet.
  • Optional 90° Prismatic Polycarbonate Reflector.
  • Rated IP65 Wet Location and designed for shock resistance with multiple heat-sinks for maximum heat dissipation.
  • It has anti-UV Clear NSF Rated Polycarbonate Lens for even light transmission and to prevent discoloration.
  • Available with Occupancy, Bi-Level Dimming, Daylight and Sensor Program Remote options.
  • Suitable for commercial and industrial locations: gymnasiums, warehouses, manufacturing, packaging, aisles, and covered decks.
  • 5 year /50000 hour warranty, and listed with all applicable bodies for safety and performance to qualify for energy-efficient LED lighting rebates.
Model: ETH-UFO-100W-G2 Applications: , , Group:

Available Color Temperature

5000K

5000K

Optional Controls & Sensors

  • Bi-Level + Photocell-W

    Twist-Lock PIR Bi-Level Dimming and Daylight Sensor, White Cap

  • HD03R Remote

    Remote Controller to Program Sensor

  • HD05R Remote

    Remote Controller with On-Screen LCD Display to Program Sensor

  • ESRPU

    EnOcean EasyFit™ Single-Rocker Pad for Self-Powered Wireless Switch

  • EDRPU

    EnOcean EasyFit™ Double-Rocker Pad for Self-Powered Wireless Switch

  • ELLSU

    EnOcean EasyFit™ Ceiling Mounted Wireless Light Level Sensor (Daylight Harvesting Module)

  • EOSCU

    EnOcean EasyFit™ Ceiling Mounted Wireless Occupancy Sensor (CR2032 Battery Optional)

  • EOSWU

    EnOcean EasyFit™ Wall Mounted Wireless Occupancy Sensor (CR2032 Battery Optional)

  • LEDDU

    EnOcean EasyFit™ Wireless LED Zone Controller 0-10V without Relay - 12V Aux Input

  • LEDRU

    EnOcean EasyFit™ Wireless LED Relay Zone Controller with 0-10V Dimming Capability

  • NWC 300U

    EnOcean EasyFit™ Navigan™ Wireless Commissioner

Technical Information

Additional information

Input Voltage

120-277V

Wattage

100W

Efficacy

152 lm/W

CCT

5000K

Lumens

15401

Dimmable

0-10V

Color

Black

Diffuser

Clear

Lens Type

NSF Rated

IP Rating

Dry Location, IP65 Wet Location

Input Frequency

50/60 Hz

CRI

Ra>80

THD

<15%

Power Factor

>0.9

L70

75000 hrs

Mounting Height

≥25-FT

Operating Temperature

-4°F to 113°F (-20°C to 45°C)

Dimensions

ø 9.40"C x 5.00"H

Net Weight

4.00 lbs

Warranty

7yr/75K
