WSD-CP95W

    WSD SERIES - LED Slim Gas Station Canopy Light, 95W, 125 lm/W, Wet Location, 1-10V Dimmable, Premium Outdoor Luminaire, Smart Sensor Ready. (120-277V)

    In stock

    • The WSD-CP95W is an industry-leading 95W LED Slim Gas Station Canopy Light luminaire producing 125 lumens per watt.
    • Wet Location rated and designed with multiple heat-sinks for maximum heat dissipation.
    • Includes slim profile with anti-UV Clear Tempered Glass Lens for 100% light transmission and to prevent discoloration.
    • Suitable for gas filling station canopies.
    • 5 year /50000 hour warranty, and listed with all applicable bodies for safety and performance to qualify for energy-efficient LED lighting rebates.

    SPEC SHEET | MORE FILES

    Model: WSD-CP95W Categories: , Tag:

    Applications

    Premium outdoor luminaire for surface mounting in ceiling spaces. Suitable for gas station canopies, parking garages, and high ceiling indoor showrooms.

    Construction

    Manufactured for weather-proof durability using solid heavy duty die cast aluminum housing with anti-UV polyester coating to resist water, salt, corrosion, discoloration, and scratching. Wet Location rated.

    Electrical

    Input voltages 120-277V with 1-10V Continuous Dimming. Operating temperatures -22°F to 113°F (-30°C to 45°C).

    Mounting

    Surface mounted installation.

    Optics

    Anti-UV Clear Tempered Glass Lens.

    Controls

    Fixture integrated Microwave Bi-Level Dimming Sensor with Photocell and Remote Controller available.

    Listings

    UL certified to meet US and Canadian standards. FCC, and RoHS compliant. Listed to qualify for energy-efficient LED lighting rebates.

    Warranty

    5 yr /50K hrs

    Available Color Temperature

    5000K

    Optional Controls & Sensors

      Specifications

      Additional information

      Energy DataInput Voltage: 120-277V
      Input Frequency: 50/60 Hz
      Wattage: 95W
      Power Factor: >0.95
      Operating Temperature: -22°F to 113°F (-30°C to 45°C)
      Lighting DataLumens: 11875
      Efficacy: 125 lm/W
      CCT: 5000K
      Dimmable: 1-10V
      CRI: Ra≥70
      L70: 50000 hrs
      Physical DataColor: White
      Lens Type: Tempered Glass
      Diffuser: Clear
      Rating: UL Wet Location
      Warranty: 5yr/50K
