FI-TWP-H-80/60/45W-G4-50K

    FI G4 SERIES - LED 3-Wattage Semi Cutoff Wall Pack, 80W Max, 150 lm/W, Select 3X-Wattages, IP65 Wet Location, 0-10V Dimmable, Premium Outdoor Luminaire. (120-277V)

    In stock

    • The FI-TWP-H-80/60/45W-G4-50K is an industry-leading 80W Max 3X-Wattage Tunable LED Semi Cutoff Wall Pack luminaire producing 150 lumens per watt.
    • 3X-Wattage Tunable (Select between 45W, 60W, 80W)
    • Includes a Silicone Water Repellent Ring, Wattage Tuning Switch and Mounting Level inside housing.
    • Rated IP65 Wet Location, designed with wide heat-sinks for maximum heat dissipation.
    • Anti-UV Prismatic Tempered Glass Lens for crisp light transmission and to prevent discoloration.
    • Available with installed Photocell Sensor.
    • 7 year /75000 hour warranty, and listed with all applicable bodies for safety and performance to qualify for energy-efficient LED lighting rebates.

    SPEC SHEET | MORE FILES

    Model: FI-TWP-H-80/60/45W-G4-50K Categories: , , Tag:

    Applications

    Premium outdoor luminaire suitable for building exteriors, entryways, courtyards, alleys, pedestrian walkways, and general security.

    Construction

    Manufactured for weather-proof durability using solid heavy duty die cast aluminum housing with anti-UV polyester coating to resist water, salt, corrosion, discoloration, and scratching. IP65 Wet Location rated for dust-tight, water jets: IEC 60529.

    Electrical

    Input voltages 120-277V models with 0-10V Continuous Dimming. Includes 3X-Wattage Tuning Switches inside housing. Operating temperatures -4°F to 113°F (-20°C to 45°C).

    Mounting

    Wall mounted installation. Includes Mounting Level inside housing.

    Optics

    Anti-UV Clear Prismatic Tempered Glass Lens.

    Listings

    UL certified to meet US and Canadian standards. FCC, and RoHS compliant. Listed to qualify for energy-efficient LED lighting rebates.

    Warranty

    7 yr /75K hrs

    Available Color Temperatures

    5000K

    5000K

    Specifications

    Additional information

    Energy DataInput Voltage: 120-277V
    Input Frequency: 50/60 Hz
    Wattage: 3X-Wattage Select (45W, 60W, 80W)
    Power Factor: >0.9
    THD: ≤20%
    Operating Temperature: -4°F to 113°F (-20°C to 45°C)
    Lighting DataLumens: (6750, 9000, 12000)
    Efficacy: 150 lm/W
    CCT: 5000K
    Dimmable: 0-10V
    CRI: Ra≥80
    L70: 75000 hrs
    Physical DataColor: Dark Bronze
    Lens Type: Tempered Glass
    Diffuser: Prismatic
    Rating: IP65 Wet Location
    Warranty: 7yr/75K
