FI-CES-D27W-40E

    CES G3 SERIES - LED Commercial Down Light, 27W, 86 lm/W, IP42 Wet Location, 1-10V Dimmable, Premium Indoor Luminaire, Smart Sensor Ready. (100-277V)

    In stock

    • The FI-CES-D27W-40E is a heavy duty commercial-grade 27W LED Down Light Engine producing 86 lumens per watt.
    • Snap locks into 6-in, 8-in, or 10-in Round Trim options and available with mounting frames for new construction.
    • Anti-UV Frosted Polycarbonate Lens for even light transmission and to prevent discoloration.
    • Designed with multiple heat-sinks for maximum heat dissipation.
    • 5 year /50000 hour warranty, and listed with all applicable bodies for safety and performance to qualify for energy-efficient LED lighting rebates.

    SPEC SHEET | MORE FILES

    Model: FI-CES-D27W-40E Categories: , Tag:

    Applications

    Premium indoor luminaire for recessed mounting in ceiling spaces. Suitable for general indoor, lobbies, offices, meeting rooms, restrooms, hallways, hospitals, airports, hotels, restaurants and shopping centers.

    Construction

    Interchangeable snap-in Light Engine and Trim size options. Manufactured for durability using aluminum sheet housing with satin white trim lip to resist corrosion, discoloration, and scratching. Includes external driver with junction box and two 14 inch whips. IP42 Wet Location rated for protection against solid objects 1.0mm diameter and greater, protection against vertically falling water drops with enclosure tilted: IEC 60529. Deep recessed lens to minimize ambient glare.

    Electrical

    Input voltage 100-277V with 1-10V Continuous Dimming. Operating temperatures -4°F to 113°F (-20°C to 45°C).

    Mounting

    Installs into most existing recessed 6-in, 8-in, and 10-in light housing frames. Compatible housing frames for new construction available.

    Optics

    Anti-UV Frosted Polycarbonate Lens.

    Listings

    UL certified to meet US and Canadian standards. FCC, CE and RoHS compliant. ENERGY STAR listed to qualify for energy-efficient LED lighting rebates.

    Warranty

    5 yr /50K hrs.

    Available Color Temperatures

    4000K

    4000K

    5000K

    5000K

    Optional Controls & Sensors

      • IP710-LFZ

        LEVITON™ 0-10V Wired Slide Dimmer (120-277V)

      • LEDRU

        EnOcean EasyFit™ Wireless LED Relay Zone Controller with 0-10V Dimming Capability, 902 MHz Frequency

      • LEDDU

        EnOcean EasyFit™ Wireless LED Zone Controller 0-10V without Relay - 12V Aux Input, 902 MHz Frequency

      • EOSCU

        EnOcean EasyFit™ Ceiling Mounted Wireless Occupancy Sensor (CR2032 Battery Optional), 902 MHz Frequency

      • EOSWU

        EnOcean EasyFit™ Wall Mounted Wireless Occupancy Sensor (CR2032 Battery Optional), 902 MHz Frequency

      • ELLSU

        EnOcean EasyFit™ Ceiling Mounted Wireless Light Level Sensor (Daylight Harvesting Module), 902 MHz Frequency

      • ESRPU

        EnOcean EasyFit™ Single-Rocker Pad for Self-Powered Wireless Switch, 902 MHz Frequency

      • EDRPU

        EnOcean EasyFit™ Double-Rocker Pad for Self-Powered Wireless Switch, 902 MHz Frequency

      • NWC 300U

        EnOcean EasyFit™ Navigan™ Wireless Commissioner

      Specifications

      Additional information

      Energy DataInput Voltage: 100-277V
      Input Frequency: 50/60 Hz
      Wattage: 27W
      Power Factor: >0.9
      THD: ≤20%
      Operating Temperature: -4°F to 113°F (-20°C to 45°C)
      Lighting DataLumens: 2322
      Efficacy: 86 lm/W
      CCT: 4000K, 5000K
      Dimmable: 1-10V
      CRI: Ra≥80
      L70: 50000 hrs
      Physical DataSize: 6-in, 8-in, 10-in
      Color: Silver with White Lip Trim
      Lens Type: Polycarbonate
      Diffuser: Frosted
      Rating: IP42 Wet Location
      Warranty: 5yr/50K
